• 1/2.8" 2.4MP CMOS Image Sensor (0.9071 centimetres)
• Max 25/30fps@2.4MP
• DWDR, 2D-DNR, AWB, AGC, BLC
• 3.6mm Fixed lens (2.8mm Optional)
• Illumination Distance of 20 Mtrs, IP67
• Support 24/7 color Imaging
• Support Built-in Mic
• CVI/CVBS/AHD/TVI switchable

Image Sensor1/2.8" 2.4MP CMOS (0.9071 centimetres)Minimum Illumination0.01Lux/F1.6, 0 Lux white light onBodyTypeDomeShutter SpeedPAL: 1/25~1/100000s NTSC: 1/30~1/100000sMax ApertureF1.6White BalanceAuto/ManualLens TypeFixedLens3.6mm (2.8mm Optional)Gain Control (AGC)Auto/ManualDORI Distance2.8mm: 43.9m (Detect) 17.5m (Observe) 8.8m (Recognize) 4.4mm (Identify) 3.6mm: 55.2m (Detect) 22.1m (Observe) 11.0m (Recognize) 5.5mm (Identify)Angle of View2.8mm: 126.2° × 106° × 56.5° (diagonal × horizontal × vertical) 3.6mm: 103.6° × 86.9° × 46.3° (diagonal × horizontal × vertical)S/N Ratio>65dBBack Light Comp.BLC/ DWDRVideo StreamingCVI: PAL: 1080P@25fps; 720P@25fps; NTSC: 1080P@30fps; 720P@30fps; AHD: PAL: 1080P@25fps; NTSC: 1080P@30fps TVI: PAL: 1080P@25fps; NTSC: 1080P@30fps; CVBS: PAL: 960H; NTSC: 960HPrivacy MaskOff/On (8 area, rectangle)Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC portAudio InputBuilt-in MicIllumination DistanceIR Distance of 20 Mtr., Smart LightOperating Temperature-40°C ~ +55°C; Less than <95% RH (non-condensation)Power Source12V DC ±30%Power ConsumptionMax 3.1W (12V DC, White Light on)Weatherproof StandardIP67Dimensionφ97 mm × 86.6 mmCasingPlastic
